Experts in rheology, polymers and additives.
Our Performance Additives business unit aspires to be a reliable and expert partner for producers of adhesives and sealants, paints and varnishes, printing inks, and construction chemical products.
Combining comprehensive raw material expertise for the specified fields of application and advanced laboratories, we are able to continually develop new products and applications, whilst still ensuring excellent technical support to our partners. As both an independent distributor and an experienced producer, we are able to work closely with customers to obtain significant benefits.
Additives
LUVOTIX® Manufacturer: Lehmann&Voss&Co.
| Products | Description | Application |
|---|---|---|
| LUVOTIX® R | Castor oil derivative | For various applications in low to medium polar systems at moderate temperatures |
| LUVOTIX® R-RF | Castor oil derivative, inorganically modified | Free-flowing and easy dispersible for highly filled systems |
| LUVOTIX® ZR 50 | Castor oil derivative, inorganically modified | For use in solvent-free and high solid formulations such as putties and sealants |
| LUVOTIX® HT | Castor oil derivative, polyamide-modified | Temperature stabilized, for various applications in low to medium polar systems |
| LUVOTIX® HT-SF | Castor oil derivative, polyamide-modified | Fine grade of LUVOTIX HT, for easier activation |
| LUVOTIX® ZH 5 | Castor oil derivative, polyamide-modified, with inorganic content | Free-flowing and easy dispersible |
| LUVOTIX® ZH 50 | Castor oil derivative, polyamide-modified, with inorganic content | For highly filled systems containing medium to higher polar solvents |
| LUVOTIX® R400 | Castor oil derivative | Process additive and flow modifier |
| LUVOTIX® HT400 | Castor oil derivative, polyamide-modified | Process additive and flow modifier |
| LUVOTIX® HP | Polyamide | For solvent-based and -free systems of medium and higher polarity |
| LUVOTIX® AB | Blend of polyamides | Sag control in high gloss and highly filled systems of medium and higher polarity |
| LUVOTIX® SAB | Blend of polyamides | Sag control and anti-settling action, especially recommended for high-gloss systems based on acrylate or polyester |
| LUVOTIX® PAB | Blend of polyamides | Control of rheological properties in gloss top-coats and in primers |
| LUVOTIX® P 100-15 | Polyolefin | Anti-settling, slight viscosity increase |
| LUVOTIX® VP031 | Polyolefin/stearic acid derivative hybrid | Easy activation, for high built coatings, sealants and adhesives based on MS-polymer |
| LUVOTIX® P25X | Polyolefin paste, 25% in xylene | Anti-settling action and sag control |
| LUVOTIX® PA2080-1 | Polyamide pastes, 20% in xylene/alcohol | Anti-settling action, sag control and thixotropy |
| LUVOTIX® PA2080-1B | Polyamide pastes, 20% in butyl acetate/alcohol | Anti-settling action, sag control and thixotropy |
LUVOGEL® Manufacturer: Lehmann&Voss&Co.
| Products | Description | Application |
|---|---|---|
| LUVOGEL® 4 LUVOGEL® 4 B LUVOGEL® 40 VP | Montmorillonite, organically modified | For low to medium polar systems, polar activator recommended |
| LUVOGEL® 7 LUVOGEL® 7 B | Montmorillonite, organically modified | For medium to high polar systems, polar activator recommended |
| LUVOGEL® SA 1 | Montmorillonite, organically modified | For a wide range of polarity, self-activating |
| LUVOGEL® SA 10 | Montmorillonite, organically modified | For low-polar aliphatic systems, selfactivating |
| LUVOGEL® SA 11 VP | Montmorillonite, organically modified, self-activating | For systems of low to medium polarity |
LUVOTIX® - Organic rheology additives for water-based systems
LUVOTIX® ATAC are synthetic associative thickeners for water-based formulations, which are supplied as low-viscous acrylic emulsions. The anionic polymers develop viscosity after neutralization in the pH-range from 7.0 to 10.0.
Different shear-thinning rheological profiles can be achieved depending on the hydrophobic modifications of the molecules.
| Products | Description | Application |
|---|---|---|
| LUVOTIX® ATAC L 100 | Hydophobically-modified associative thickener based on HASE | LUVOTIX® ATAC L 100 is a hydrophobically-modified associative thickener used in waterborne adhesives, sealants, paints and coatings to improve both storage stability and sag resistance and settling behavior. LUVOTIX® ATAC L 100 produces a highly pseudoplastic flow profile in waterborne formulations and is particularly recommended to increase viscosity in the low to medium shear range. |
| LUVOTIX® ATAC M 400 | Non-associative thickener, based on ASE | LUVOTIX® ATAC M 400 is a VOC-free non-associative thickener for waterborne formulations and is used in paints, coatings as well as sealants and adhesives to improve color acceptance and wet abrasion. LUVOTIX® ATAC M 400 produces a highly pseudoplastic flow profile in waterborne formulations and is particularly recommended to increase the viscosity in all shear ranges. |
| LUVOTIX® ATAC H 700 | Hydophobically-modified associative thickener based on HASE | LUVOTIX® ATAC H 700 is a hydrophobically-modified anionic thickener for waterborne adhesives, sealants, paints, lacquers, and protective coatings. Use of LUVOTIX® ATAC H 700 improves the storage stability, levelling, and anti-splash system properties. LUVOTIX® ATAC H 700 produces a Newtonian flow profile in waterborne formulations and is particularly recommended to increase the viscosity in the high shear range. |
LUVOTIX® ATUR are non-ionic hydrophobically modified polyurethanes used in water-based formulations, independent of pH-range. By tailored modifications of molecular structures, any desired rheological profile from newtonian to strong shear thinning can be obtained. LUVOTIX® ATUR are specifically designed for glossy, high-quality coatings when excellent surface levelling properties are desired after application.
| Products | Description | Application |
|---|---|---|
| LUVOTIX® ATUR L 200 | Hydophobically-modified polyurethane thickener based on HEUR | LUVOTIX® ATUR L 200 is a hydrophobically-modified biobased polyurethane thickener. LUVOTIX® ATUR L 200 is used in waterborneadhesives, sealants, and paints and coatings and improves the rub-out resistance, storage stability and chemical/water resistance. LUVOTIX® ATUR L 200 is APEO- and VOC- free and is particularly recommended to increase viscosity in the low shear range. |
| LUVOTIX® ATUR M 500 | Hydophobically-modified polyurethane thickener based on HEUR | LUVOTIX® ATUR M 500 is a hydrophobically modified polyurethane thickener for waterborne adhesives, sealants, paints, lacquers and protective coatings that improves the levelling, spraying and sag resistance of waterborne formulations. LUVOTIX® ATUR M 500 has a pseudoplastic flow behavior and is particularly recommended for increasing viscosity in the medium shear rate range. |
| LUVOTIX® ATUR M 510 | Hydophobically-modified polyurethane thickener based on HEUR | LUVOTIX® ATUR M 510 is a hydrophobically-modified polyurethane thickener for waterborne adhesives, sealants, paints, lacquers, and protective coatings that improves levelling, spraying and sag resistance. LUVOTIX® ATUR M 510 has a pseudoplastic flow behavior and is particularly recommended to increase viscosity in the medium shear range. |
| LUVOTIX® ATUR M 600 | Hydophobically-modified polyurethane thickener based on HEUR | LUVOTIX® ATUR M 600 is a hydrophobically-modified polyurethane thickener for waterborne adhesives, sealants, paints, and coatings that improves levelling, settling and sagging of waterborne formulations. LUVOTIX® ATUR M 600 has a pseudoplastic flow behavior and is particularly recommended to increase viscosity in the medium shear range. |
| LUVOTIX® ATUR H 800 | Hydophobically-modified polyurethane thickener based on HEUR | LUVOTIX® ATUR H 800 is a hydrophobically-modified polyurethane thickener for waterborne formulations, used in adhesives, sealants, paints, lacquers, and protective coatings to improve properties such as levelling, wet abrasion, and film formation. LUVOTIX® ATUR H 800 has a Newtonian flow behavior and is particularly recommended to increase viscosity in the high shear range. LUVOTIX® ATUR H 800 can be effectively combined with LUVOTIX® ATUR L 200. |
LUVOGEL® - Inorganic rheology additives for solvent-based and water-based systems
Naturally occurring and organically modified phyllosilicates from the LUVOGEL® series are used in water-based and solvent-based systems for rheology control. The powdered additives are incorporated directly at the beginning of the dispersing process or in form of pre-gels. Polar chemical activators are sometimes added to increase gel formation in solvent-based systems. Easily dispersible and self-activating LUVOGEL® additives enable fast and successful activation processes without the necessity to control the temperature.
| Products | Description | Application |
|---|---|---|
| LUVOGEL® W1 | Montmorillonite
| LUVOGEL® W1 is used in water-based formulations, e.g. adhesives, paints and coatings, cleaning agents, polishes, etc. It produces a pseudoplastic flow profile with thixotropic properties and improves settling behavior and flow control. |
| LUVOGEL® W3 | Montmorillonite
| LUVOGEL® W3 is used in water-based formulations, e.g. adhesives, paints and coatings, cleaning agents, polishes, etc. It produces a pseudoplastic flow profile with thixotropic properties and improves settling behavior and flow control. |
| LUVOGEL® AQ | Synthetic Hectorite | LUVOGEL® AQ is mainly used as a rheological additive in water-based formulations. The main areas of application are industrial coatings and automotive paints – OEM as well as After-Market. The products provide excellent stabilisation and orientation of effect pigments. |
| LUVOGEL® W2N | Synthetic Hectorite | LUVOGEL® W2N is mainly used as a rheological additive in water-based formulations. The main areas of application are industrial coatings and automotive paints – OEM as well as After-Market. The products provide excellent stabilisation and orientation of effect pigments. |
| LUVOGEL® WS1 | Synthetic Hectorite | LUVOGEL® WS1 is a synthetic smectite clay modified by an inorganic sodium phosphate. It is used as a rheological additive in water-based formulations. |
| LUVOGEL® WS2 | Synthetic Hectorite | LUVOGEL® WS2 is a synthetic smectite clay modified by an inorganic sodium phosphate. It is used as a rheological additive in water-based formulations. |
WOLLATROP® - Inorganic rheology additives for water-based systems
WOLLATROP® are hydrated and inverted ribbon silicates that are used as inorganic thickeners in water-based systems. The additives are particularly easy to incorporate into formulations thanks to their filamentous and flexible structure. Unlike classic phyllosilicates, WOLLATROP® products develop a stable structure immediately after incorporation, which leads to increased viscosity, especially in the low shear rate range. WOLLATROP® products are characterized by a high tolerance to changes in ionic strength and pH fluctuations.
| Product | Description | Application |
|---|---|---|
| WOLLATROP®-S | Ribbon silicates with fine fiber distribution | Preferred use in paints, varnishes and coatings. |
| WOLLATROP®-SE | Ribbon silicates with fine fiber distribution | Preferred use in paints, varnishes and coatings. |
| WOLLATROP®-M | Absorbent filler based on ribbon silicates | Application as rheology additive in construction chemical products such as mortars, construction and tile adhesives, fillers and filling compounds, but also high build coatings and wall or facade paints. Particularly suitable for use at high temperature. |
| WOLLATROP®-LV | Silicate fibers, organically modified | Preferred use in water-based coatings with low to medium layer thickness as well as in construction chemical products, such as adhesives or plasters. |
| WOLLATROP®-S/240 | Silicate hybrid | WOLLATROP®-S/240 is an economical rheology additive. It can be used as a multifunctional rheology additive in construction chemical products or high build coatings that require micro-reinforcement or crack bridging in addition to rheological adjustment. |
Functional Fillers
Closed cell perlite based hollow microspheres TRI-SPHERES®
Description
TRI-SPHERES® are hollow multi-cellular microspheres with a popcorn structure on a silicate basis. TRI-SPHERES® serve as functional lightweight fillers. Their heat resistance is up to 1,500 °C. Their compressive strength ends at 3,260 PSI / 22.5 Mpa. With a view to any shear forces occurring during the incorporation, their multi-cellular structure avoids that all spheres are destroyed at high forces. TRI-SPHERES® are marked by a clear bright colour.
Application
TRI-SPHERES® can be used as lightweight fillers in many different applications such as paints and coatings, foams in composites as well as in hydraulic-setting cement for construction chemistry (TRI-SPHERES® 120 XL). With a view to the optimisation of acoustic and thermal properties, TRI-SPHERES® 270, 300 and 352 are recommended. In particular the fine TRI-SPHERES® 45XS Ultra achieves good results in partial weight reduction of PP polymer for injection mouldingwhen adding 10 – 15 % as an additive for the last step.
| Products | D10 [μm] | D90 [μm] | Bulk density [kg/m³] | Crush strength [psi] | Effective density [kg/m³] |
|---|---|---|---|---|---|
| TRI-SPHERES® 120XL | 450 | 1.050 | 120 | < 725 | - |
| TRI-SPHERES® 200 | 100 | 340 | 200 | < 725 | 440 |
| TRI-SPHERES® 250 | 100 | 500 | 250 | - | 520 |
| TRI-SPHERES® 270 | 150 | 350 | 270 | - | 580 |
| TRI-SPHERES® 300 | 75 | 270 | 300 | 725 | 610 |
| TRI-SPHERES® 352 | 115 | 275 | 350 | 1.030 | 800 |
| TRI-SPHERES® 402 | 115 | 245 | 400 | 1.581 | 890 |
| TRI-SPHERES® 450 | 75 | 230 | 450 | 2.176 | 720 |
| TRI-SPHERES® 300S | 70 | 135 | 300 | 1.015 | 660 |
| TRI-SPHERES® 400S | 75 | 160 | 400 | 1.421 | 690 |
| TRI-SPHERES® 45XS ULTRA | 35 | 80 | 450 | 3.263 | 960 |
The stated values correspond to typical values and hence do not represent a specification.
tri-spheres©.pdfCenospheres OMEGA-SPHERES®
Hollow ceramic microspheres are extremely resistant hollow spheres, which are formed under the exposure of extreme heat. Temperatures over the relevant melting points are required to achieve a ceramic melting. Drops with a hollow are formed as a result of the subsequent rapid cooling process. The OMEGA-SPHERES® formed in this way are refined and fractionated in subsequent processes, thus being a high-quality raw material in your formulations.
The spheres we provide are produced at various production sites for global availability. Globally produced standard types are manufactured in the Ukraine and Germany. Special types are produced in Germany. There are further suppliers in Europe and throughout the world.
OMEGA-SPHERES®, Grey
Description
OMEGA-SPHERES® are hollow ceramic microspheres > 150 μm which are used as functional lightweight filler is several industries. OMEGA-SPHERES® are characterised by a high thermal and mechanic resistance and are available in different distribution particle sizes.
Application
Because of their weight-reducing and insulating properties, OMEGA-SPHERES® are used preferentially in construction chemical products such as adhesives and sealants. They are also used as pore generators in friction and brake linings as well as in grinding and separating tools.
| Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
|---|---|---|---|---|
| OMEGA-SPHERES® 150 | 0 - 150 | 390 | 14 | 1,200 |
| OMEGA-SPHERES® 300 | 0 - 300 | 400 | 14 | 1,200 |
| OMEGA-SPHERES® SG | 0 - 500 | 400 | 14 | 1,200 |
| OMEGA-SPHERES® G250-6 | 250 - 700 | 400 | 14 | 1,200 |
The stated values correspond to typical values and hence do not represent a specification.
omega-spheres®,-grey.pdfOMEGA-SPHERES®, White
Description
OMEGA-SPHERES® W are marked by a particularly high thermal resistance, low iron content and a white colour. They are available in different distribution particle sizes.
Application
Because of their particularly high heat resistance, OMEGA-SPHERES® W are preferentially used in the refractory and foundry industries. The white colour allows their use in aesthetically demanding applications such as decorative plasters and wall paints.
| Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
|---|---|---|---|---|
| OMEGA-SPHERES® W150 | 0 - 150 | 410 | 25 | 1,600 |
| OMEGA-SPHERES® W300 | 0 - 300 | 410 | 25 | 1,600 |
| OMEGA-SPHERES® WM | 150 - 300 | 390 | 25 | 1,600 |
| OMEGA-SPHERES® W250-6 | 250 - 700 | 400 | 25 | 1,600 |
The stated values correspond to typical values and hence do not represent a specification.
omega-spheres®,-white.pdfCenospheres THERMO-SPHERES®
THERMO-SPHERES®, Grey
Description
THERMO-SPHERES® G are high quality hollow ceramic microspheres < 150 μm, which are characterised by a high degree of fineness as well as a particularly high mechanical strength. The products are pre-dried. Because of the high fineness, they display good grinding properties and are, therefore, highly suitable as insulation and lightweight filling materials.
Application
THERMO-SPHERES® G are used in applications which require the use of particularly small hollow microspheres or make high demands on surface finish. This includes, apart from the use in paints and coatings, composite materials, special casting compounds and putties, adhesives and sealants.
| Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
|---|---|---|---|---|
| THERMO-SPHERES® G75 | 0 - 75 | 350 | 14 | 1,200 |
| THERMO-SPHERES® G100 | 0 - 100 | 400 | 14 | 1,200 |
The stated values correspond to typical values and hence do not represent a specification.
thermo-spheres®,-grey.pdfTHERMO-SPHERES® White
Description
THERMO-SPHERES® W are white, high quality hollow ceramic microspheres < 150 μm, which are characterised by a high degree of fineness as well as a particularly high mechanical strength. The products are pre-dried and usable for foundry industry. The white colour allows their use in aesthetically demanding applications such as decorative plasters and wall paints.
Application
THERMO-SPHERES® W are used in bright applications which require the use of the smallest possible microspheres or make high demands on surface quality. This includes applications in addition to the use in paints and coatings, surfaces as well as special casting compounds and adhesives where a high whiteness is advantageous.
| Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
|---|---|---|---|---|
| THERMO-SPHERES® W100 | 0 - 100 | 400 | 25 | 1,600 |
| THERMO-SPHERES® W125 | 0 - 125 | 400 | 25 | 1,600 |
The stated values correspond to typical values and hence do not represent a specification.
thermo-spheres®,-white.pdfOMEGA-SIL®
Description
OMEGA-SIL® are solid aluminium silicate spheres which have a very high compressive strength. The OMEGA-SIL® SPECIAL* product range consists of aluminium silicates that are processed in an additional processing step sifted. This particularly sharp separation of the top cut results in aesthetic applications to smoother surfaces.
Application
Due to the lower specific surface the use of OMEGA-SIL® in paints and coatings allows a higher degree of filling. OMEGA- SIL® shows in cementitious systems pozzolanic reactivity. The inside microcrystalline structure results in a significant increase of mechanical strength.
| Products | D50 [μm] | D95 [μm] | Effective density [g/cm³] | Bulk density [kg/m³] |
|---|---|---|---|---|
| OMEGA-SIL® XS | 3.5 | 9.5 | 2.51 | 780 |
| OMEGA-SIL® S | 4.5 | 11.5 | 2.48 | 800 |
| OMEGA-SIL® M | 6.5 | 30.0 | 2.40 | 870 |
| OMEGA-SIL® L | 12.5 | 75.0 | 2.39 | 880 |
| OMEGA-SIL® XL | 50.0 | 200.0 | 2.25 | 1,090 |
| OMEGA-SIL® XS SPECIAL | 3.5 | 9.5* | 2.51 | 780 |
| OMEGA-SIL® S SPECIAL | 4.5 | 11.5* | 2.48 | 800 |
| OMEGA-SIL® M SPECIAL | 6.5 | 30.0* | 2.40 | 870 |
Product items shown with an asterisk * describe top cut (d98) modified versions for aesthetical surfaces.
The stated values correspond to typical values and hence do not represent a specification.
OMEGA-BUBBLES® C - ultra white
OMEGA-BUBBLES® C are multicellular expanded glass granules. The high whiteness can help to reduce the addition of titanium dioxide in cementitious formulation. For aesthetic applications like acoustic construction or ceilings the ultra-white lightweight fillers meet today's spirit of time. OMEGA-BUBBLES® C being based on selected recycled glass. Using these products is sustainable and environmentally friendly and can reduces your green CO2 footprint in later disposal issues.
OMEGA-BUBBLES® C are available in the grain sizes customary on the market for the construction and insulation industry.
| Products | Particle size range [mm] | Grain gross density [kg/m³] | Bulk density [kg/m³] |
|---|---|---|---|
| OMEGA-BUBBLES® C-XS | 0.1 - 0.3 | 680 - 920 | 340 - 460 |
| OMEGA-BUBBLES® C-S | 0.25 - 0.5 | 460 - 620 | 255 - 345 |
| OMEGA-BUBBLES® C-M | 0.5 - 1.0 | 380 - 510 | 210 - 290 |
| OMEGA-BUBBLES® C-L | 1.0 - 2.0 | 310 - 420 | 190 - 250 |
| OMEGA-BUBBLES® C-XL | 2.0 - 4.0 | 260 - 360 | 160 - 220 |
The stated values correspond to typical values and hence do not represent a specification.
omega-bubbles®-c-–-ultra-white.pdf
