Experts in rheology, polymers and additives.
Our Performance Additives business unit aspires to be a reliable and expert partner for producers of adhesives and sealants, paints and varnishes, printing inks, and construction chemical products.
Combining comprehensive raw material expertise for the specified fields of application and advanced laboratories, we are able to continually develop new products and applications, whilst still ensuring excellent technical support to our partners. As both an independent distributor and an experienced producer, we are able to work closely with customers to obtain significant benefits.
Additives
LUVOTIX® Manufacturer: Lehmann&Voss&Co.
| Products | Description | Application |
|---|---|---|
| LUVOTIX® R | Castor oil derivative | For various applications in low to medium polar systems at moderate temperatures |
| LUVOTIX® R-RF | Castor oil derivative, inorganically modified | Free-flowing and easy dispersible for highly filled systems |
| LUVOTIX® ZR 50 | Castor oil derivative, inorganically modified | For use in solvent-free and high solid formulations such as putties and sealants |
| LUVOTIX® HT | Castor oil derivative, polyamide-modified | Temperature stabilized, for various applications in low to medium polar systems |
| LUVOTIX® HT-SF | Castor oil derivative, polyamide-modified | Fine grade of LUVOTIX HT, for easier activation |
| LUVOTIX® ZH 5 | Castor oil derivative, polyamide-modified, with inorganic content | Free-flowing and easy dispersible |
| LUVOTIX® ZH 50 | Castor oil derivative, polyamide-modified, with inorganic content | For highly filled systems containing medium to higher polar solvents |
| LUVOTIX® R400 | Castor oil derivative | Process additive and flow modifier |
| LUVOTIX® HT400 | Castor oil derivative, polyamide-modified | Process additive and flow modifier |
| LUVOTIX® HP | Polyamide | For solvent-based and -free systems of medium and higher polarity |
| LUVOTIX® AB | Blend of polyamides | Sag control in high gloss and highly filled systems of medium and higher polarity |
| LUVOTIX® SAB | Blend of polyamides | Sag control and anti-settling action, especially recommended for high-gloss systems based on acrylate or polyester |
| LUVOTIX® PAB | Blend of polyamides | Control of rheological properties in gloss top-coats and in primers |
| LUVOTIX® P 100-15 | Polyolefin | Anti-settling, slight viscosity increase |
| LUVOTIX® VP031 | Polyolefin/stearic acid derivative hybrid | Easy activation, for high built coatings, sealants and adhesives based on MS-polymer |
| LUVOTIX® P25X | Polyolefin paste, 25% in xylene | Anti-settling action and sag control |
| LUVOTIX® PA2080-1 | Polyamide pastes, 20% in xylene/alcohol | Anti-settling action, sag control and thixotropy |
| LUVOTIX® PA2080-1B | Polyamide pastes, 20% in butyl acetate/alcohol | Anti-settling action, sag control and thixotropy |
LUVOGEL® Manufacturer: Lehmann&Voss&Co.
| Products | Description | Application |
|---|---|---|
| LUVOGEL® 4 LUVOGEL® 4 B LUVOGEL® 40 VP | Montmorillonite, organically modified | For low to medium polar systems, polar activator recommended |
| LUVOGEL® 7 LUVOGEL® 7 B | Montmorillonite, organically modified | For medium to high polar systems, polar activator recommended |
| LUVOGEL® SA 1 | Montmorillonite, organically modified | For a wide range of polarity, self-activating |
| LUVOGEL® SA 10 | Montmorillonite, organically modified | For low-polar aliphatic systems, selfactivating |
| LUVOGEL® SA 11 VP | Montmorillonite, organically modified, self-activating | For systems of low to medium polarity |
LUVOGEL® Manufacturer: Lehmann&Voss&Co.
| Products | Description | Application |
|---|---|---|
| LUVOGEL® W1 | Montmorillonite, organically modified | Anti-settling agent |
| LUVOGEL® W2N | Synthetic hectorite | Thickening agent forming strong thixotropy for pigmented and transparent systems |
| LUVOGEL® W3 | Montmorillonite, organically modified | Anti-settling and thixotropic agent |
WOLLATROP® Manufacturer: Lehmann&Voss&Co.
Inorganic thickeners of the WOLLATROP® series are based on inosilicate technology. This technology has a similar effect to the well-known phyllosilicate thickeners, but behaves very differently in the high shear range. Due to the thread-like structure, alignment in the printing direction is possible, which allows easier processing than comparable phyllosilicates.
The WOLLATROP® series permits the use of inorganic thickeners in aqueous systems. Their valued properties in the high shear range as well as their strong thixotropic effect support an excellent product. By combining different types it is possible to create a rheology profile tailored to the needs of the user. With different processes it is possible to significantly influence the thickening effect.
| Series | Product | Description | Applications |
|---|---|---|---|
| WOLLATROP®-S Series | WOLLATROP®-S | Specially prepared, 100% mineral silicate additives with a particularly high active surface Improvement in the sagging behaviour of coatings and reduction in the settling of pigments and fillers | Preferred in building chemistry applications such as building adhesives and sealing compounds. Rheological adjustment for water-based paints and lacquers. |
| WOLLATROP®-SE | |||
| WOLLATROP®-SF | |||
| WOLLATROP®-S/240 | WOLLATROP®-S/240 is a 100% natural mineral compound which acts as a very good thixotropic agent. | Crack bridging in building chemicals, adhesives, sealants and putties | |
| WOLLATROP®-LV | WOLLATROP®-LV is a silicate additive which has been given a particularly high active surface area by a special digestion process. WOLLATROP®-LV reduces sagging and settling of pigments and fillers. | Water-borne paints and lacquers Building chemicals | |
| WOLLATROP®-M | WOLLATROP®-M is based on hydrous magnesium silicate and controls the rheology by absorption of the solvent. Especially recommended for higher temperatures.
| Higher temperature applications |
Functional Fillers
Hollow ceramic microspheres are extremely resistant hollow spheres, which are formed under the exposure of extreme heat. Temperatures over the relevant melting points are required to achieve a ceramic melting. Drops with a hollow are formed as a result of the subsequent rapid cooling process. The OMEGA-SPHERES® formed in this way are refined and fractionated in subsequent processes, thus being a high-quality raw material in your formulations.
The spheres we provide are produced at various production sites for global availability. Globally produced standard types are manufactured in the Ukraine and Germany. Special types are produced in Germany. There are further suppliers in Europe and throughout the world.
Closed cell perlite based hollow microspheres TRI-SPHERES®
Description
TRI-SPHERES® are hollow multi-cellular microspheres with a popcorn structure on a silicate basis. TRI-SPHERES® serve as functional lightweight fillers. Their heat resistance is up to 1,500 °C. Their compressive strength ends at 2,900 PSI / 20 Mpa. With a view to any shear forces occurring during the incorporation, their multi-cellular structure avoids that all spheres are destroyed at high forces. TRI-SPHERES® are marked by a clear bright colour.
Application
TRI-SPHERES® can be used as lightweight fillers in many different applications such as paints and coatings, foams in composites as well as in hydraulic-setting cement for construction chemistry (TRI-SPHERES® 120 XL). With a view to the optimisation of acoustic and thermal properties, TRI-SPHERES® 300 and 400 are recommended. In particular the fine TRI-SPHERES® 45XS Ultra achieves good results in partial weight reduction of PP polymer for injection mouldingwhen adding 10 – 15 % as an additive for the last step.
| Products | D50 [μm] | D50 [μm] | Bulk density [kg/m³] | Crush strength [psi] | Effective density [kg/m³] |
|---|---|---|---|---|---|
| TRI-SPHERES® 45XS ULTRA | 40 | 80 | 450 | 1,450 | - |
| TRI-SPHERES® 300S | 70 | 135 | 300 | 1,160 | 550 |
| TRI-SPHERES® 400S | 75 | 160 | 400 | 623 | 650 |
| TRI-SPHERES® 500S | 75 | 140 | 500 | 1,305 | - |
| TRI-SPHERES® 200 | 100 | 375 | 200 | 130 | 340 |
| TRI-SPHERES® 250 | 100 | 500 | 250 | - | - |
| TRI-SPHERES® 300 | 75 | 270 | 300 | 319 | 500 |
| TRI-SPHERES® 350 | 100 | 290 | 350 | - | - |
| TRI-SPHERES® 400 | 100 | 400 | 400 | 667 | 670 |
| TRI-SPHERES® 450 | 75 | 230 | 450 | 725 | 720 |
| TRI-SPHERES® 90XL | 200 | 700 | 90 | 21 | 190 |
| TRI-SPHERES® 100XL | 700 | 1,700 | 90 | 36 | 210 |
| TRI-SPHERES® 120XL | 400 | 800 | 120 | 50 | 200 |
The stated values correspond to typical values and hence do not represent a specification.
tri-spheres©.pdfCenospheres OMEGA-SPHERES®
OMEGA-SPHERES®, Grey
Description
OMEGA-SPHERES® are hollow ceramic microspheres > 150 μm which are used as functional lightweight filler is several industries. OMEGA-SPHERES® are characterised by a high thermal and mechanic resistance and are available in different distribution particle sizes.
Application
Because of their weight-reducing and insulating properties, OMEGA-SPHERES® are used preferentially in construction chemical products such as adhesives and sealants. They are also used as pore generators in friction and brake linings as well as in grinding and separating tools.
| Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
|---|---|---|---|---|
| OMEGA-SPHERES® 150 | 0 - 150 | 390 | 14 | 1,200 |
| OMEGA-SPHERES® 300 | 0 - 300 | 400 | 14 | 1,200 |
| OMEGA-SPHERES® SG | 0 - 500 | 400 | 14 | 1,200 |
| OMEGA-SPHERES® G250-6 | 250 - 700 | 400 | 14 | 1,200 |
The stated values correspond to typical values and hence do not represent a specification.
omega-spheres®,-grey.pdfOMEGA-SPHERES®, White
Description
OMEGA-SPHERES® W are marked by a particularly high thermal resistance, low iron content and a white colour. They are available in different distribution particle sizes.
Application
Because of their particularly high heat resistance, OMEGA-SPHERES® W are preferentially used in the refractory and foundry industries. The white colour allows their use in aesthetically demanding applications such as decorative plasters and wall paints.
| Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
|---|---|---|---|---|
| OMEGA-SPHERES® W150 | 0 - 150 | 410 | 25 | 1,600 |
| OMEGA-SPHERES® W300 | 0 - 300 | 410 | 25 | 1,600 |
| OMEGA-SPHERES® WM | 150 - 300 | 390 | 25 | 1,600 |
| OMEGA-SPHERES® W250-6 | 250 - 700 | 400 | 25 | 1,600 |
The stated values correspond to typical values and hence do not represent a specification.
omega-spheres®,-white.pdfCenospheres THERMO-SPHERES®
THERMO-SPHERES®, Grey
Description
THERMO-SPHERES® G are high quality hollow ceramic microspheres < 150 μm, which are characterised by a high degree of fineness as well as a particularly high mechanical strength. The products are pre-dried. Because of the high fineness, they display good grinding properties and are, therefore, highly suitable as insulation and lightweight filling materials.
Application
THERMO-SPHERES® G are used in applications which require the use of particularly small hollow microspheres or make high demands on surface finish. This includes, apart from the use in paints and coatings, composite materials, special casting compounds and putties, adhesives and sealants.
| Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
|---|---|---|---|---|
| THERMO-SPHERES® G75 | 0 - 75 | 350 | 14 | 1,200 |
| THERMO-SPHERES® G100 | 0 - 100 | 400 | 14 | 1,200 |
The stated values correspond to typical values and hence do not represent a specification.
thermo-spheres®,-grey.pdfTHERMO-SPHERES® White
Description
THERMO-SPHERES® W are white, high quality hollow ceramic microspheres < 150 μm, which are characterised by a high degree of fineness as well as a particularly high mechanical strength. The products are pre-dried and usable for foundry industry. The white colour allows their use in aesthetically demanding applications such as decorative plasters and wall paints.
Application
THERMO-SPHERES® W are used in bright applications which require the use of the smallest possible microspheres or make high demands on surface quality. This includes applications in addition to the use in paints and coatings, surfaces as well as special casting compounds and adhesives where a high whiteness is advantageous.
| Products | Particle size [μm] | Bulk density [kg/m³] | Crush strength [MPa] | Temperature max. [°C] |
|---|---|---|---|---|
| THERMO-SPHERES® W75 | 0 - 75 | 400 | 25 | 1,600 |
| THERMO-SPHERES® W100 | 0 - 100 | 400 | 25 | 1,600 |
| THERMO-SPHERES® W125 | 0 - 125 | 400 | 25 | 1,600 |
The stated values correspond to typical values and hence do not represent a specification.
thermo-spheres®,-white.pdfOMEGA-SIL®
Description
OMEGA-SIL® are solid aluminium silicate spheres which have a very high compressive strength. The OMEGA-SIL® SPECIAL* product range consists of aluminium silicates that are processed in an additional processing step sifted. This particularly sharp separation of the top cut results in aesthetic applications to smoother surfaces.
Application
Due to the lower specific surface the use of OMEGA-SIL® in paints and coatings allows a higher degree of filling. OMEGA- SIL® shows in cementitious systems pozzolanic reactivity. The inside microcrystalline structure results in a significant increase of mechanical strength.
| Products | D50 [μm] | D95 [μm] | Effective density [g/cm³] | Bulk density [kg/m³] |
|---|---|---|---|---|
| OMEGA-SIL® XS | 3.5 | 9.5 | 2.51 | 780 |
| OMEGA-SIL® S | 4.5 | 11.5 | 2.48 | 800 |
| OMEGA-SIL® M | 6.5 | 30.0 | 2.40 | 870 |
| OMEGA-SIL® L | 12.5 | 75.0 | 2.39 | 880 |
| OMEGA-SIL® XL | 50.0 | 200.0 | 2.25 | 1,090 |
| OMEGA-SIL® XS SPECIAL | 3.5 | 9.5* | 2.51 | 780 |
| OMEGA-SIL® S SPECIAL | 4.5 | 11.5* | 2.48 | 800 |
| OMEGA-SIL® M SPECIAL | 6.5 | 30.0* | 2.40 | 870 |
Product items shown with an asterisk * describe top cut (d98) modified versions for aesthetical surfaces.
The stated values correspond to typical values and hence do not represent a specification.
OMEGA-BUBBLES© C - ultra white
OMEGA-BUBBLES® C are multicellular expanded glass granules. The high whiteness can help to reduce the addition of titanium dioxide in cementitious formulation. For aesthetic applications like acoustic construction or ceilings the ultra-white lightweight fillers meet today's spirit of time. OMEGA-BUBBLES® C being based on selected recycled glass. Using these products is sustainable and environmentally friendly and can reduces your green CO2 footprint in later disposal issues.
OMEGA-BUBBLES® C are available in the grain sizes customary on the market for the construction and insulation industry.
| Products | Particle size range [mm] | Grain gross density [kg/m³] | Bulk density [kg/m³] |
|---|---|---|---|
| OMEGA-BUBBLES® C-XS | 0.1 - 0.3 | 680 - 920 | 340 - 460 |
| OMEGA-BUBBLES® D-S | 0.25 - 0.5 | 460 - 620 | 255 - 345 |
| OMEGA-BUBBLES® C-M | 0.5 - 1.0 | 380 - 510 | 210 - 290 |
| OMEGA-BUBBLES® C-L | 1.0 - 2.0 | 310 - 420 | 190 - 250 |
| OMEGA-BUBBLES® C-XL | 2.0 - 4.0 | 260 - 360 | 160 - 220 |
The stated values correspond to typical values and hence do not represent a specification.
omega-bubbles©-c-–-ultra-white.pdf
OMEGA-BUBBLES© D
Description
OMEGA-BUBBLES® D are multi-cellular, closed cell expanded glass granules which serve as functional lightweight filler. OMEGA-BUBBLES® D have fire class A1 and a thermal conductivity of 0.07 W/mK. They are resistant to pressure, humidity and acid and are characterised by acoustically insulating properties.
Application
OMEGA-BUBBLES® D-XS and D-S are used in READY-TO-USE plasters and paints. The types OMEGA-BUBBLES® D-M to D-XL are preferentially applied in plasters, mortars and other construction chemical products. In adhesives, grinding and friction applications OMEGA-BUBBLES® D have turned out to be effective spacers and pore-forming agents.
| Products | Particle size range [mm] | Grain gross density [kg/m³] | Bulk density [kg/m³] |
|---|---|---|---|
| OMEGA-BUBBLES® D-XS | 0,1 - 0,3 | 680 - 920 | 340 - 460 |
| OMEGA-BUBBLES® D-S | 0,25 - 0,5 | 460 - 620 | 255 - 345 |
| OMEGA-BUBBLES® D-M | 0,5 - 1,0 | 380 - 510 | 210 - 290 |
| OMEGA-BUBBLES® D-L | 1,0 - 2,0 | 310 - 420 | 190 - 250 |
| OMEGA-BUBBLES® D-XL | 2,0 - 4,0 | 260 - 360 | 160 - 220 |
The stated values correspond to typical values and hence do not represent a specification.
omega-bubbles®-d.pdfVideo Surface Technology (Oberflächentechnik)
